TYPE: HRA-2816
NAME:?28Al roller conveyor
Roller is made of aluminium alloy which is good for rust resistance,light self weight,suitable for special requiring situation.
>>details
1.roller diameter:?28mm(tube thickness:1.6mm)
2.frame： 60mm U-Al
3.width: 100mm～500mm
4.Load capacity: max63kg
>>Spe.
(U: mm)
| roller width W (mm) | 100 | 200 | 300 | 400 | 500 | ||
| roller load capacity (kg) | 63 | 54 | 35 | 30 | 21 | ||
| conveyor weight 3,000L (kg) | 40P | 13.5 | 18.0 | 22.6 | 27.1 | 31.7 | |
| 50P | 12.0 | 15.7 | 19.4 | 23.2 | 26.9 | ||
| roller weight(shaft) (g) | 100 | 155 | 210 | 265 | 320 | ||
| SPE. | OD(φ)×shell thickness(t) bearing | shaft OD(φ)×shell thickness(t) production | frame sizeI×K×t machine height(H) | machine length L | roller width W | roller pitch P | bend radius R R | ||||||
| RA-2816 | 28×1.6 alumina cutting bearing | 8×1.2 pipe zinc plating semi-circle | [ 60×30×3 alumina 66 | 1000/1,500 2,000/3,000 | 100～500 any sizes | 40/50 75 | 900 | ||||||
